Caméra |
|
Capteur D'image |
CMOS 2 MP |
Résolution
|
1920 (H) × 1080 (V) |
Min. Éclairage |
0,01 Lux @ (F2.0, AGC ON), 0 Lux avec IR |
Temps D'obturation |
PAL : 1/25 s à 1/50 000 s ; NTSC : 1/30 s à 1/50 000 s |
Jour Nuit |
Filtre anti-IR |
Réglage De L'angle |
Panoramique : 0° à 360°, Inclinaison : 0° à 75°, Rotation : 0° à 360° |
Lentille |
|
Type D'objectif |
Objectif à focale fixe DE 2,8 mm/3,6 mm |
Distance Focale Et Champ De Vision |
2,8 mm, champ de vision horizontal : 106,4°, champ de vision vertical : 57,9°, champ de vision diagonal : 124,6° 3,6 mm, champ de vision horizontal : 79,6°, champ de vision vertical : 43,5°, champ de vision diagonal : 93,7° 6 mm, champ de vision horizontal : 51,9°, champ de vision vertical : 30°, champ de vision diagonal : 58,8° |
Monture De Lentilles |
M12 |
Image |
|
Mode Jour/Nuit |
Auto/Couleur/NB (noir et blanc)
|
Large Plage Dynamique (WDR) |
WDR numérique |
Balance Des Blancs |
Automatique/MANUEL
|
Interface
|
|
Sortie Vidéo |
TVI/AHD/CVI/CVBS commutables
|
Microphone Intégré |
Oui
|
Général |
|
Consommation |
12 VCC ± 25 %, max. 3,7 W |
Matériel |
Métal
|
État De Fonctionnement |
-40 °C à 60 °C (-40 °F à 140 °F), humidité 90 % ou moins (sans condensation)
|
Dimensions |
82,6 mm × 90 mm × 79,37 mm (3,25" × 3,54" × 3,12")
|
Poids |
Environ. 292 g (0,64 livre)
|
